  • Vantage ACF-60 Cal-Hypo Feeder and Systems - ACF60
  • Vantage ACF-60 Cal-Hypo Feeder and Systems - ACF60

Vantage ACF-60 Cal-Hypo Feeder and Systems

Maintaining Beautiful pool water has never been this easy!

The ACF-60 was designed for easy service. Two removable panels on the top and lower tank provide easy access to hose out the basin or remove and clean components. The scrubbing action of the rinse nozzle, combined with the smooth surfaces of the feeder help reduce scale buildup.

3 configurations to choose from:
  • Model ACF-60, complete with installation component kit
  • Model ACF-60 with overflow shut-off, for flooded systems or extra assurance against main circulation system disruption or performance.
  • Model ACF-60 with booseter pump, to assure adequate flows through the system independant of main circulation system performance, skid mounted for ease of instalation.

Features and Specifications:
  • Inlet Flow: 1.0 - 2.0 gpm
  • Outlet Flow: = Inlet Flow
  • Inlet Pressure: 10 - 45 psi
  • Maximum Output: 80 lbs. of Available Cl2 per Day
  • Capacity: 60 lbs. of Vantage� Calcium Hypochlorite Tablets
  • Feeder Height 31.5�
  • Feeder Width 14.5�
  • Feeder Depth 20�
  • Feeder weight (full) 110 lbs.
  • Feeder weight (empty) 50 lbs.
  • Tubing 5/8� O.D.
  • For Swimming Pool Use Only
  • Recommended Pool Size up to 200,000 US Gallons
    Know someone who might like this? - Please, feel free to " Tell A Friend "


    Item # Description/Size Qty Break Price Quantity
    ACF-60
    Vantage Cal-Hypo Tablet Feeder - Model ACF-60
    		 1 $2,296.25
    ACF-60B
    Vantage Cal-Hypo Tablet Feeder - Model ACF-60 B, less overflow
    		 1 $1,336.00
    ACF-60S
    Vantage Cal-Hypo Tablet Feeder - Model ACF-60, Skid Mounted System
    		 1 $3,832.65

    Easily installed and easy to service, the Vantage ACF-60 Calcium Hypochlorite Feeder is designed for the commercial pool operator's convenience. With a hopper that holds 60 pounds of Vantage Calcium Hypochlorite Tablets, it can handle pools up to 200,000 gallons. What's more, it can easily be installed in tandem in order to provide less frequent filling of the feeder when used on larger pools. The design also provides many safety features for the operator.

    The ACF-60 was designed for easy service. Two removable panels on the top and lower tank provide easy access to hose out the basin or remove and clean components. The scrubbing action of the rinse nozzle, combined with the smooth surfaces of the feeder, will reduce scale buildup.

    Features

    • For up to 200K gallon pools
    • Runs "clean" - less maintenance
    • Simple, Efficient, Durable
    • Use Vantage Calcium Hypo Tablets only
    • Most parts are interchangeable
    • NSF/ANSI Standard 50 Certified
